Hybrid Modeling

What is hybrid modeling?

Hybrid modeling comes into the picture when a single modeling technique cannot provide the required features and capabilities necessary to make a project successful.

Hybrid modeling combines both solid and surface modeling techniques to create complex 3D models in computer-aided design (CAD) software.  Designers use it to craft models with more accurate and intricate shapes than solid or surface modeling alone. Hybrid modeling lets designers quickly make complex shapes and perform necessary edits.

Hybrid modeling can incorporate elements from machine learning, logical programming, or artificial intelligence. Hybrid models are valuable in many fields, including computer vision, natural language processing, and robotics.

Types of hybrid modeling

There are typically four types of hybrid modeling that are combined into a common workflow. The types of hybrid modeling data leveraged are as follows:

• Boundary representation modeling: Boundary representation modeling (BRep) modeling is the most common approach in CAD applications. The geometric borders between solid and non-solid geometries define BRep, a mathematical term representing a 3D object.
  A BRep object's form and edges can't create reducible elements like polygons or vertices. Instead, the mathematical interactions between a BRep object's surfaces determine it.
• Polygonal model data: For video game developers and animation studios, polygonal (or polyhedral) modeling is the most popular type. Triangular or polygonal smaller building blocks are used in this sort of modeling to create three-dimensional (3D) objects (polygons).
  The location of each polygon or triangle connecting edges and vertices (or points) determines the shape's flatness. A complex model is constructed of any shape entirely from tris or polys. Designers can increase the number of polygons in their models as they demand more "high-fidelity" designs (such as surfaces with a smoother appearance and more features).
• Point-cloud data (3D scanned objects): Point-cloud modeling is frequently applied while 3D scanning items. Point cloud modeling represents a 3D object with densely distributed vertices or "points" throughout its surface instead of defining surfaces by mathematical formulas or building them out of simple shapes like triangles.
  Point-cloud models can faithfully depict the features of almost any 3D object with a high enough resolution and point density. Point-cloud 3D scanning creates 3D models of highly complex objects like human faces.
• Voxel data (3D images for volumetric imaging): Like pixels are 2D, voxels are 3D. Pixels are the tiny squares that make up what is visible on the computer screen. These days, computers have a high resolution because pixels aren’t visible. Instead of a pixelated screen, viewers only see smooth text, images, and symbols.  Voxels are effectively 3D pixels. However, they are perfect cubes rather than squares.

Hybrid modeling process

Traditionally, BRep is used to create a model. Then, CAD conversion software is used to translate this data into a different format than that of the BRep. Once the data has been translated, the required changes are made. However, this is a lengthy and time-consuming process. This is where hybrid modeling comes into the picture. A hybrid modeling process combines the benefits of BRep, polygonal, point-cloud, and voxel-based modeling into one workflow.

Hybrid modeling allows designers and developers to move back and forth between the different modeling types without losing data. Engineers can run any simulation of BRep files and use these insights to tweak their models. This back-and-forth between the environments is the process of hybrid modeling.

Benefits of hybrid modeling

Hybrid modeling has several benefits. Some of them are listed here:

• Increased efficiency: Hybrid modeling in CAD allows designers to create complex shapes and surfaces.
• Improved accuracy: Hybrid modeling provides higher accuracy than traditional CAD modeling because it uses multiple technologies for more precise design.
• Enhanced creativity: Designers devise unique creations that are difficult to make with traditional CAD modeling.
• Reduced costs: Hybrid modeling eliminates the need to purchase multiple CAD software packages.
• Increased flexibility: Designers find it simple to switch between different technologies.

Limitations of hybrid modeling

Understanding the challenges that come with hybrid modeling is important. Listed below are some of its limitations.

• Hybrid modeling is a complex process that requires the user to have a thorough understanding of the different modeling techniques and the software used to create the model.
• Hybrid models often require many components that take time to assemble and manage.
• Complex hybrid models may require a long time to build and can be difficult to modify or update.
• Hybrid models may require additional software for certain tasks.
• Hybrid modeling is often more costly than other modeling techniques due to the increased complexity and software requirements.

Tap into next level modeling and learn about 3D printing to help streamline prototyping and production of 3D models.
